TinyVision V851 使用 AWOL Tina Linux 支持 OpenCV 开启摄像头

#ifdef __USE_VIN_ISP__
bool CvCaptureCAM_V4L::RAWSensor()
{
    struct v4l2_control ctrl;
    struct v4l2_queryctrl qc_ctrl;

    memset(&ctrl, 0, sizeof(struct v4l2_control));
    memset(&qc_ctrl, 0, sizeof(struct v4l2_queryctrl));
    ctrl.id = V4L2_CID_SENSOR_TYPE;
    qc_ctrl.id = V4L2_CID_SENSOR_TYPE;

    if (-1 == ioctl (deviceHandle, VIDIOC_QUERYCTRL, &qc_ctrl)){
        fprintf(stderr, "V4L2: %s QUERY V4L2_CID_SENSOR_TYPE failed\n", deviceName.c_str());
        return false;
    }

    if (-1 == ioctl(deviceHandle, VIDIOC_G_CTRL, &ctrl)) {
        fprintf(stderr, "V4L2: %s G_CTRL V4L2_CID_SENSOR_TYPE failed\n", deviceName.c_str());
        return false;
    }

    return ctrl.value == V4L2_SENSOR_TYPE_RAW;
}
#endif

#ifdef __USE_VIN_ISP__
	RawSensor = RAWSensor();

	if (startStream && RawSensor) {
		int VideoIndex = -1;

		sscanf(deviceName.c_str(), "/dev/video%d", &VideoIndex);

		IspPort = CreateAWIspApi();
		IspId = -1;
		IspId = IspPort->ispGetIspId(VideoIndex);
		if (IspId >= 0)
			IspPort->ispStart(IspId);
	} else if (RawSensor && IspId >= 0 && IspPort) {
		IspPort->ispStop(IspId);
		DestroyAWIspApi(IspPort);
		IspPort = NULL;
		IspId = -1;
	}
#endif

#include <fcntl.h>
#include <fstream>
#include <iostream>
#include <linux/fb.h>
#include <signal.h>
#include <stdint.h>
#include <sys/ioctl.h>

#include <opencv2/opencv.hpp>

#define DISPLAY_X 240
#define DISPLAY_Y 240

static cv::VideoCapture cap;

struct framebuffer_info {
    uint32_t bits_per_pixel;
    uint32_t xres_virtual;
};

struct framebuffer_info get_framebuffer_info(const char* framebuffer_device_path)
{
    struct framebuffer_info info;
    struct fb_var_screeninfo screen_info;
    int fd = -1;
    fd = open(framebuffer_device_path, O_RDWR);
    if (fd >= 0) {
        if (!ioctl(fd, FBIOGET_VSCREENINFO, &screen_info)) {
            info.xres_virtual = screen_info.xres_virtual;
            info.bits_per_pixel = screen_info.bits_per_pixel;
        }
    }
    return info;
};

/* Signal handler */
static void terminate(int sig_no)
{
    printf("Got signal %d, exiting ...\n", sig_no);
    cap.release();
    exit(1);
}

static void install_sig_handler(void)
{
    signal(SIGBUS, terminate);
    signal(SIGFPE, terminate);
    signal(SIGHUP, terminate);
    signal(SIGILL, terminate);
    signal(SIGINT, terminate);
    signal(SIGIOT, terminate);
    signal(SIGPIPE, terminate);
    signal(SIGQUIT, terminate);
    signal(SIGSEGV, terminate);
    signal(SIGSYS, terminate);
    signal(SIGTERM, terminate);
    signal(SIGTRAP, terminate);
    signal(SIGUSR1, terminate);
    signal(SIGUSR2, terminate);
}

int main(int, char**)
{
    const int frame_width = 480;
    const int frame_height = 480;
    const int frame_rate = 30;

    install_sig_handler();

    framebuffer_info fb_info = get_framebuffer_info("/dev/fb0");

    cap.open(0);

    if (!cap.isOpened()) {
        std::cerr << "Could not open video device." << std::endl;
        return 1;
    }

    std::cout << "Successfully opened video device." << std::endl;
    cap.set(cv::CAP_PROP_FRAME_WIDTH, frame_width);
    cap.set(cv::CAP_PROP_FRAME_HEIGHT, frame_height);
    cap.set(cv::CAP_PROP_FPS, frame_rate);

    std::ofstream ofs("/dev/fb0");

    cv::Mat frame;
    cv::Mat trams_temp_fream;
    cv::Mat yuv_frame;

    while (true) {
        cap >> frame;
        if (frame.depth() != CV_8U) {
            std::cerr << "Not 8 bits per pixel and channel." << std::endl;
        } else if (frame.channels() != 3) {
            std::cerr << "Not 3 channels." << std::endl;
        } else {
            cv::transpose(frame, frame);
            cv::flip(frame, frame, 0);
            cv::resize(frame, frame, cv::Size(DISPLAY_X, DISPLAY_Y));
            int framebuffer_width = fb_info.xres_virtual;
            int framebuffer_depth = fb_info.bits_per_pixel;
            cv::Size2f frame_size = frame.size();
            cv::Mat framebuffer_compat;
            switch (framebuffer_depth) {
            case 16:
                cv::cvtColor(frame, framebuffer_compat, cv::COLOR_BGR2BGR565);
                for (int y = 0; y < frame_size.height; y++) {
                    ofs.seekp(y * framebuffer_width * 2);
                    ofs.write(reinterpret_cast<char*>(framebuffer_compat.ptr(y)), frame_size.width * 2);
                }
                break;
            case 32: {
                std::vector<cv::Mat> split_bgr;
                cv::split(frame, split_bgr);
                split_bgr.push_back(cv::Mat(frame_size, CV_8UC1, cv::Scalar(255)));
                cv::merge(split_bgr, framebuffer_compat);
                for (int y = 0; y < frame_size.height; y++) {
                    ofs.seekp(y * framebuffer_width * 4);
                    ofs.write(reinterpret_cast<char*>(framebuffer_compat.ptr(y)), frame_size.width * 4);
                }
            } break;
            default:
                std::cerr << "Unsupported depth of framebuffer." << std::endl;
            }
        }
    }
}

// 引入头文件
#include <fcntl.h>
#include <fstream>
#include <iostream>
#include <linux/fb.h>
#include <signal.h>
#include <stdint.h>
#include <sys/ioctl.h>

#include <opencv2/opencv.hpp>

// 定义显示屏宽度和高度
#define DISPLAY_X 240
#define DISPLAY_Y 240

static cv::VideoCapture cap; // 视频流捕获对象

// 帧缓冲信息结构体
struct framebuffer_info {
    uint32_t bits_per_pixel; // 每个像素的位数
    uint32_t xres_virtual; // 虚拟屏幕的宽度
};

// 获取帧缓冲信息函数
struct framebuffer_info get_framebuffer_info(const char* framebuffer_device_path)
{
    struct framebuffer_info info;
    struct fb_var_screeninfo screen_info;
    int fd = -1;

    // 打开帧缓冲设备文件
    fd = open(framebuffer_device_path, O_RDWR);
    if (fd >= 0) {
        // 通过 ioctl 获取屏幕信息
        if (!ioctl(fd, FBIOGET_VSCREENINFO, &screen_info)) {
            info.xres_virtual = screen_info.xres_virtual; // 虚拟屏幕的宽度
            info.bits_per_pixel = screen_info.bits_per_pixel; // 每个像素的位数
        }
    }
    return info;
}

/* Signal handler */
static void terminate(int sig_no)
{
    printf("Got signal %d, exiting ...\n", sig_no);
    cap.release();
    exit(1);
}

static void install_sig_handler(void)
{
    signal(SIGBUS, terminate); // 当程序访问一个不合法的内存地址时发送的信号
    signal(SIGFPE, terminate); // 浮点异常信号
    signal(SIGHUP, terminate); // 终端断开连接信号
    signal(SIGILL, terminate); // 非法指令信号
    signal(SIGINT, terminate); // 中断进程信号
    signal(SIGIOT, terminate); // IOT 陷阱信号
    signal(SIGPIPE, terminate); // 管道破裂信号
    signal(SIGQUIT, terminate); // 停止进程信号
    signal(SIGSEGV, terminate); // 无效的内存引用信号
    signal(SIGSYS, terminate); // 非法系统调用信号
    signal(SIGTERM, terminate); // 终止进程信号
    signal(SIGTRAP, terminate); // 跟踪/断点陷阱信号
    signal(SIGUSR1, terminate); // 用户定义信号1
    signal(SIGUSR2, terminate); // 用户定义信号2
}

int main(int, char**)
{
    const int frame_width = 480;
    const int frame_height = 480;
    const int frame_rate = 30;

    install_sig_handler(); // 安装信号处理函数

    framebuffer_info fb_info = get_framebuffer_info("/dev/fb0"); // 获取帧缓冲区信息

    cap.open(0); // 打开摄像头

    if (!cap.isOpened()) {
        std::cerr << "Could not open video device." << std::endl;
        return 1;
    }

    std::cout << "Successfully opened video device." << std::endl;
    cap.set(cv::CAP_PROP_FRAME_WIDTH, frame_width);
    cap.set(cv::CAP_PROP_FRAME_HEIGHT, frame_height);
    cap.set(cv::CAP_PROP_FPS, frame_rate);

    std::ofstream ofs("/dev/fb0"); // 打开帧缓冲区

    cv::Mat frame;
    cv::Mat trams_temp_fream;
    cv::Mat yuv_frame;

    while (true) {
        cap >> frame; // 读取一帧图像
        if (frame.depth() != CV_8U) { // 判断是否为8位每通道像素
            std::cerr << "Not 8 bits per pixel and channel." << std::endl;
        } else if (frame.channels() != 3) { // 判断是否为3通道
            std::cerr << "Not 3 channels." << std::endl;
        } else {
            cv::transpose(frame, frame); // 图像转置
            cv::flip(frame, frame, 0); // 图像翻转
            cv::resize(frame, frame, cv::Size(DISPLAY_X, DISPLAY_Y)); // 改变图像大小
            int framebuffer_width = fb_info.xres_virtual;
            int framebuffer_depth = fb_info.bits_per_pixel;
            cv::Size2f frame_size = frame.size();
            cv::Mat framebuffer_compat;
            switch (framebuffer_depth) {
            case 16:
                cv::cvtColor(frame, framebuffer_compat, cv::COLOR_BGR2BGR565);
                for (int y = 0; y < frame_size.height; y++) {
                    ofs.seekp(y * framebuffer_width * 2);
                    ofs.write(reinterpret_cast<char*>(framebuffer_compat.ptr(y)), frame_size.width * 2);
                }
                break;
            case 32: {
                std::vector<cv::Mat> split_bgr;
                cv::split(frame, split_bgr);
                split_bgr.push_back(cv::Mat(frame_size, CV_8UC1, cv::Scalar(255)));
                cv::merge(split_bgr, framebuffer_compat);
                for (int y = 0; y < frame_size.height; y++) {
                    ofs.seekp(y * framebuffer_width * 4);
                    ofs.write(reinterpret_cast<char*>(framebuffer_compat.ptr(y)), frame_size.width * 4);
                }
            } break;
            default:
                std::cerr << "Unsupported depth of framebuffer." << std::endl;
            }
        }
    }

    return 0;
}
